Atomos

StudioSonic Shotgun Mic

Professional-grade wireless/wired shotgun microphone

237,00€ (ex. VAT)

SKU: ATOMSSMC01 Category: Brand:

Professional-grade wireless/wired shotgun microphone with locking USB-C and full broadcast feature set. Its dual-mode design offers the flexibility to operate wirelessly over 2.4GHz or via a direct USB-C digital audio connection to ensure a secure, professional-grade link to cameras, monitors, and computers. The StudioSonic Shotgun Mic caters for a diverse range of scenarios, including on-location interviews, run-and-gun shooting, field reporting, and capturing unscripted dialog. Its high quality 48kHz/24-bit super cardioid design isolates voices with precision, even in noisy environments.

Key features

  • Broadcast clarity. Built for production. — The Atomos StudioSonic Shotgun Microphone delivers professional-grade audio capture in a compact, rugged form—ideal for filmmakers, content creators,…
  • Precision Directional Pickup — Featuring a supercardioid polar pattern, the StudioSonic shotgun mic isolates your subject from background noise, making it perfect for interviews,…
  • Plug-and-Play Simplicity — The StudioSonic runs on plug-in power and connects via standard 3.5mm TRS, making it compatible with a wide range of cameras, recorders, and audio…
  • Built for Production Environments — With a rugged metal body and low handling noise, the StudioSonic is ready for real-world shooting conditions.
  • Compact and Lightweight — Weighing just 82 grams, the StudioSonic stays out of the way whether you’re mounting it on a boom pole, hot shoe, or compact handheld rig.
  • Key Features — • Supercardioid shotgun microphone for focused directional audio• High-sensitivity capsule with excellent off-axis rejection• Plug-in power via 3.5mm…
  • What’s in the box? — • StudioSonic Shotgun Microphone• Shockmount• Foam windscreen• Furry windshield• 3.5mm TRS cable• Quick Start Guide — Hear the audio from the mic in…
Physical
Dimensions Transmitter: Φ22mm x L224mm, Receiver: 54mm x 48mm x 22mm
Weight Transmitter: 94gms, Receiver: 29.5gms
Environmental
Ambient operating temperature Up to 40 degrees Celsius
Construction & Control
Body Aluminium alloy (mic); ABS (receiver)
Power
Battery Transmitter: Li-polymer 3.7V 350mAh; Receiver: Li-polymer 3.7V 330mAh
Battery life Transmitter: Wired mode 32-50 hours; wireless mode 8-10 hours; on-board recording mode 5 hours. Receiver: 8 hours
Wi-Fi
Frequency 2.4GHz
General
Transmitting Power +10dBm
Receiving Sensitivity -96dBm
Antenna Ceramic
Sound Delay <20ms
Polar Pattern Super cardioid
Frequency Response 20Hz ~ 20kHz
Low-cut -3dB @ 100Hz
High-frequency Boost +3dB @ 10kHz
Output Impedance 600Ω
Sensitivity -38dB ~ -18dB re 1V/Pa (12mv ~ 125mv @ 94dB SPL) ±2dB @ 1kHz
S/N 75dB SPL (A-weighted, as per IEC651)
Equivalent Noise 19dB SPL (A-weighted, as per IEC651)
Maximum SPL 130dB SPL(@ 1% THD)
Dynamic Range 111dB SPL (A-weighted, as per IEC651)
Analog Output 3.5mm TRRS/TRS
Digital Output USB-C 48kHz/24-bit
Warranty
Standard 1 year. Extended to 2 years on product registration.

Additional information

Brand

Microphone, receiver, headphone cable TRS 3.5mm to TRS 3.5mm coiled (25 cm), heaphone cable TRRS 3.5 mm to TRRS 3.5mm coiled (25cm), USB-C locking cable (20cm), adjustable pole mount clip, cold shoe mount with quick release plate, microphone shock mount, windscreen, windmuff, reset pin, carry case, Quick Start Guide
