The AC 3200-II is an active 8-channel transmitter combiner for bundling antenna signals in large wireless monitoring systems. Designed for the 2000 Series rack-mount monitor transmitters, it lets up to eight signals transmit from a single antenna, with linear power amplifiers handling up to 100 mW per channel without loss and per-channel LEDs for a reliable system overview.
Features
- Combines up to 8 signals and transmits them via a single antenna
- Combines signals of up to 8 x 100 mW without loss
- Significant suppression of intermodulation between connected transmitters
- Per-channel LED status indication
Specifications
- Frequency range: 500 to 870 MHz
- RF input power: max. 100 mW (protected up to 250 mW)
- Impedance: 50 Ohm
- Power supply: 12 V DC (NT 12-125D included)
- Current consumption: max. 7.5 A
- Power consumption: max. 90 W
- Temperature range: -10 to +45 C
- Dimensions: 436 x 215 x 44 mm
- Weight: approx. 4 kg
What’s in the box
- (1) AC 3200-II Antenna booster
