FULL 4K/30 HDMI 1.4 & 6G-SDI 20X Zoom POV Camera **Replaces UHD6G-X12L**

The UHD6G-X20L combines the power of 6G-SDI and HDMI to simultaneously output uncompressed, quality 4K video.

1.423,00€ (ex. VAT)

SKU: UHD6G-X20L Categories: , , Brand:
  • 4K 1/1.7” Progressive Scan CMOS sensor capable of capturing up to 30fps over 6G-SDI and HDMI
  • Advanced digital imaging processor provides vivid and detailed images by utilizing Dynamic Range, Auto White Balance, and Noise Reduction.
  • Superb motion-compensated temporal noise reduction filter for motion video without blurring.
  • SD control breakout cable with power input and RS-485 for remote communication.
  • Flawlessly relays multi-channel embedded audio via SDI.
  • Perfectly suited for broadcast, pro audio/video, and security.
  • Conforming with SMPTE 292M, 424M, and 2081-10.
  • Versatile, compact, and rugged design with 1/4” 20 mounting on bottom.
Key Specs
Supports Color Recording
Yes
Digital I/O
1/8″ / 3.5 mm TRS Stereo / BNC / HDMI / Micro-USB
Supported Protocols
Camera Control VISCA
Imaging
Image Sensor
1/2.8″-Type CMOS
Recording
Supports Color Recording
Yes
Exposure Control
Shutter Type
Electronic Rolling Shutter
Minimum Illumination
0.1 Lux
Lens
Aperture Range
f/1.5 to 3
Interface
Digital I/O

1x BNC (6G-SDI) Video Output
1x HDMI 1.4 Video Output
1x 1/8″ / 3.5 mm TRS Stereo Audio Input
1x Micro-USB Firmware Input
Embedded Audio
HDMI
Power I/O
1x Barrel Input
Internal Storage
No
Media/Memory Card Slot
No
Connectivity
Wireless
No
Supported Protocols
Camera Control
VISCA
Mobile App Compatible
No
Power
Voltage
12.0 VDC
General
Accessory Mounting
1 x 1/4″-20 Female
Dimensions
14.6 x 6.8 x 6.8 cm
Weight
750 g
