SymplyPRO 2U Rackmount Ethernet 2x10Gb SFP LC Ethernet Host Interfaces, 12Gb SAS (SFF-8644) Expansion, and Dual Hot-Swap Drive Bays. Includes 1 x Full-Height LTO-10 tape drive (upgradable to two drives). The 12Gb SAS (SFF-8644) Expansion supports an additional 2 external SAS tape drives. The full-height LTO-10 enterprise drive boasts a native performance of 400MB/Sec (900MB/Sec compressed), a native capacity of 30TB or 40TB (depending on the data cartridge), designed for 24×7 operation, supports 256-bit encryption along with WORM media. Compatible with LTFS (Linear Tape File System) making backup and archive operations easier to an open source and interchangeable tape format. Symply tape products feature massive interoperability and are compatible with industry leading software providers. Internal Auto-Switching Power Supply (110-240v). Kit includes 1 x macOS iSCSI License, 1 x data cartridge, 1 x cleaning cartridge, 2 x 3m LC-LC OM4 Data Cables, 1 x 5m RJ45 management cable, 1 x Rack-Kit, and SymplyATOM macOS software. 3 Year Worldwide warranty, with optional extension to 5 years.
Key features
- 2U Rackmount Form Factor
- Dual 10Gb Ethernet Interface (LC & RJ45)
- Supports 2 Internal & 2 External LTO Drives
- Includes 1xLTO-10 Full-Height Tape Drive TAA (Not Backwards Compatible to LTO-9)
- LTFS drag-and-drop compatible
- Includes 3 Year Advanced Exchange Warranty & Comprehensive Accessories Kit
Compatibility
Microsoft Windows; macOS (Intel & Apple Silicon); Linux; Requires iSCSI Initiator
Resources
Product information
| Manufacturer |
Symply |
| Part number |
SYPR2-RE1LAF2B-AT |
| LTO generation |
LTO-10 |
| Drive height |
Full-Height |
| Compatibility |
Microsoft Windows; macOS (Intel & Apple Silicon); Linux; Requires iSCSI Initiator |
| Manufacturer warranty |
3 Year |
System
| Form factor |
2U rackmount (Gen2), Full-Height |
| Number of drives supported |
1 or 2 |
| LTO generations supported (chassis) |
LTO-10 |
| Host interface |
2 x 10GbE iSCSI |
| Expansion interface |
1 x SFF-8644 |
| Dimensions (D x W x H) |
43.5 x 48.2 x 8.8 cm (17.13 x 18.98 x 3.46 in) |
| Weight |
10.9 kg (24.0 lb) |
Tape drive performance & capacity (native / compressed)
| LTO-10 Enterprise (Aramid) media |
400 MB/s (1000 MB/s) · 40 TB (100 TB) |
| LTO-10 media |
400 MB/s (1000 MB/s) · 30 TB (75 TB) |
Tape drive reliability
| MTBF |
250,000 h @ 100% duty cycle |
| MSBF (mean swaps before failure) |
100,000 |
| Load / unload cycles |
300,000 |
Environmental specifications
| Operating temperature (recommended) |
15 to 25 °C (59 to 77 °F) |
| Operating temperature (allowable) |
15 to 30 °C (59 to 86 °F) |
| Non-operating temperature |
5 to 35 °C (41 to 95 °F) |
| Relative humidity |
20 to 50% recommended, 20 to 80% allowable (non-condensing) |
| Maximum altitude |
3,048 m (10,000 ft) operating, 12,192 m (40,000 ft) non-operating |
| Shipping conditions |
5 to 45 °C (41 to 113 °F); 10% to 80% RH non-condensing |
Specifications from Symply; subject to change by the manufacturer.
– Data Cartridge
– Cleaning Cartridge
– (1) 5m RJ45 Management Cable
– (2) 3m LC-LC OM4 Cable
– (1) macOS ATTO Xtend SAN iSCSI Initiator
– Rack Kit
– Worldwide power cords
– Product documentation
