SymplyPRO XTL 24 Slot 2U Gen2 Tape Library with 1 x Half-Height LTO-9 tape drive, 2x10Gb Ethernet (iSCSI) Interface, 24 Cartridge Slots in 2 removable Magazines, 1 Mail slot, Rackmount-Kit, Remote Management Console, Clean Cartridge, (2) 3m LC-LC OM4 Cable, 3m RJ45 Management Cable, Quick Start Guide, 3 years warranty Return To Base (RTB) including, 3 years Symply Pro Exchange (SPE) Service. Optional Warranty Extension to 5 years.
Key features
- Efficient 2RU Compact Library for Automated Backup and Archiving
- 24 LTO Cartridge Slots and 1 LTO-9 Half-Height Drive 2x10Gb iSCSI Interface
- 2 x 10Gb Ethernet (iSCSI) Connectivity
- Uncompressed Capacity up to 432TB with LTO-9 Media (1080TB compressed)
- Robotic MSBF 1,000,000
- 3 Years Return To Base (RTB) Warranty including Symply Pro Exchange (SPE) Service
Compatibility
Microsoft Windows; Linux; macOS(Intel & Apple Silicon); Requires a FC HBA
Resources
Product information
| Manufacturer |
Symply |
| Part number |
SYXTL-C24E1L9HA-BT |
| LTO generation |
LTO-9 |
| Drive height |
Half-Height |
| Compatibility |
Microsoft Windows; Linux; macOS(Intel & Apple Silicon); Requires a FC HBA |
| Manufacturer warranty |
3 Year |
SymplyPRO XTL 24 library
| Rack units |
2U |
| LTO drives supported |
LTO-8, 9 |
| Tape slots |
24 |
| Half-height drives |
1 or 2 |
| Mail slots (import/export) |
1 |
| Magazines |
2 |
| Max partitions |
2 |
| Barcode reader |
Yes |
| Rack mount kit |
Included |
| Native interface |
SAS (LTO-8: 6 Gb SFF-8088, LTO-9: 12 Gb SFF-8644) or Fibre Channel 8 Gb LC |
| Optional interface |
10GbE Ethernet or Thunderbolt 3 via internal module |
| Power |
Single PSU, 100-240 VAC / 160 W, 50-60 Hz |
| Robotic MSBF |
1,000,000 |
| Dimensions (H x W x D) |
87 x 482 x 806 mm (3.42 x 18.97 x 31.73 in) |
| Weight (no tape drives) |
15 kg (33 lb) |
Tape drive performance & capacity (native / compressed)
| LTO-9 media |
300 MB/s (750 MB/s) · 18 TB (45 TB) |
Tape drive reliability
| MTBF |
250,000 h @ 100% duty cycle |
| MSBF (mean swaps before failure) |
100,000 |
| Load / unload cycles |
80,000 |
Environmental specifications
| Operating temperature (recommended) |
15 to 25 °C (59 to 77 °F) |
| Operating temperature (allowable) |
15 to 30 °C (59 to 86 °F) |
| Non-operating temperature |
5 to 35 °C (41 to 95 °F) |
| Relative humidity |
20 to 50% recommended, 20 to 80% allowable (non-condensing) |
| Maximum altitude |
3,048 m (10,000 ft) operating, 12,192 m (40,000 ft) non-operating |
| Shipping conditions |
5 to 45 °C (41 to 113 °F); 10% to 80% RH non-condensing |
Specifications from Symply; subject to change by the manufacturer.
– Cleaning Cartridge
– (1) 3m RJ45 Management Cable
– (2) 3m LC-LC OM4 Cable
– (1) Power Cable
– Rack Kit
– Quick Start Guide
