Teradek

RT MOTR.S

MOTR.S is the new standard for lens motors and has been completely redesigned from the ground up. MOTR.S is ultra-lightweight, compact, and blazing fast at up to 320 rotations per minute.

1.728,76€ (ex. VAT)

SKU: 15-0050 Categories: , , Brand:

MOTR.S is the new standard for lens motors and has been completely redesigned from the ground up. MOTR.S is ultra-lightweight, compact, and blazing fast at up to 320 rotations per minute. RT users can now daisy-chain motors, utilize power inputs up to 32V, and streamline camera rigging with a revolutionary quick-release gear system and new ergonomic rod clamps. MOTR.S will be compatible with all previous RT handsets, receivers, and daisy-chainable motors (MOTR.X and MOTR.X MAX).

This add-on motor comes with one 0.8 gear. No motor cables are included.

The MOTR.S lens motor is bundled with our MOTR.S FIZ Kit and MOTR.S Single Channel Kit for full motor control of focus, iris, and/or zoom, as well as the optional MOTR.S MAX for up to 25% more torque for stiff, resistant dials on heavy-duty lenses.

Model MOTR.S
Physical
Gear Pitch 0.8 Mod standard (others available)
Max Torque 0.55 Nm peak, 0.55 Nm continuous
Max Speed 320 rotations/minute
Construction All aluminium
Mountability Compatible with 19, 15 mm Rods
Dimensions 4.1 x 2.2 x 1.2″ (106 x 56 x 31 mm)
Weight 6.5 oz (184 g)
Power
Operating Voltage 7-32V
Power Input 0.1A idle. 2.5A peak
Interface
Connectors 2x 0B.4 (chainable)
Environmental
Operating Temperature –20°C to 50°C

Additional information

Brand

  • RT MOTR.S Lens Motor
  • 0.8 MOD Gear
  • MOTR.S/MAX Bracket
