ATEM Monitoring Rack Panel 40
Blackmagic Design

ATEM Monitoring Rack Panel 40

1RU rack control panel and IP to SDI/HDMI monitoring converter with 40 buttons.

1.358,00€ (ex. VAT)

SKU: SWPANELABRMP40 Categories: , , Brand:

ATEM Monitoring Rack Panel 40 is a video converter built into a 1RU rack mount ATEM switcher control panel, for operating and monitoring an ATEM Constellation IP switcher.

Key features

  • 40 input buttons with the same controls as ATEM Constellation SDI models
  • Redundant 10G Ethernet SMPTE-2110 / SMPTE-2022-7 to 12G-SDI and HDMI converter
  • Dedicated Ethernet control port
  • 5 pin talkback interface on the front panel
  • 1RU rack mount design

Specifications

Input buttons40
ConverterRedundant 10G Ethernet SMPTE-2110 / SMPTE-2022-7 to 12G-SDI and HDMI
Talkback5 pin XLR talkback interface on the front panel
ControlDedicated Ethernet control port; same controls as ATEM Constellation SDI
Form factor1RU rack mount

Additional information

Brand

ATEM Monitoring Rack Panel 40 is a video converter built into a 1RU rack mount ATEM switcher control panel, for operating and monitoring an ATEM 4 M/E Constellation IP switcher. It has the same controls as ATEM Constellation SDI models, but works as an independent monitoring converter and control panel.
