Atomos

Shinobi GO

5-inch Touchscreen, 1500 nit, HDR Video & Photo Monitor

284,00€ (ex. VAT)

SKU: ATOMSHB004 Categories: , , Brand:

A slim, lightweight, high brightness, 5-inch 1500nit HDR monitor that’s perfect for content creators and photographers. Same basic monitoring functionality as Shinobi II, but without camera control, touch to focus, 4K DCI support, on-device calibration, EL Zone/ARRI false color or anamorphic de-squeeze.

Key features

  • Atomos Shinobi GO – Budget Camera Monitor — The Shinobi GO 5.2″ Touchscreen HDR Video/Photo Monitor is a bright, lightweight, and cost-effective addition to your camera setup.
  • AtomOS & Advanced Image Tools — Running the latest AtomOS, the Shinobi GO offers an intuitive layout with a wide selection of monitoring tools.
  • Bright Display — The 5.2″ touchscreen is rated at 1500 cd/m² peak brightness, making it easily viewable outdoors or under direct light.
  • Input Signals — An HDMI 1.4 input allows the Shinobi GO to display resolutions up to UHD 4K30 and frame rates up to 1080p60, making it versatile for a range of…
  • HDR & LUT Support — Monitor Log, PQ, or HLG footage with over 10 stops of dynamic range.
  • Frame Guides — Framing options include a wide variety of cinematic and social media aspect ratios, from 2.41 and 2.35 to 16:9, 9:16, 4:5, 1:1, and more, helping you…
  • Lightweight Design — With its slim form factor, the Shinobi GO is designed for portability and balance.
  • Power Options — Power can be supplied via standard L-series/NP-F batteries or an optional USB-C PD charger.
  • Remote Calibration — Using the LANC Remote port, the Shinobi GO can be calibrated through Atomos Calibrator software on Windows or macOS.
  • Accessories — The monitor ships with an HDMI/USB-C locking adapter, allowing you to use Atomos’ locking cable system for secure connections.
Physical
Dimensions (W x H x D mm) 151mm x 91.5mm x 20.8 mm (28.5mm with locking cable adaptor attached)
Weight 210g / 7.4oz.
Mounting Points Bottom: 1 x 1/4-inch 20 with anti-rotational points
Environmental
Ambient Operating Temperature Up to 40 degrees Celsius
Construction
Body ABS Polycarbonate Plastic
Cooling Passive heat sink
Multi-Function Button Power / Lock Screen
Touch Screen Capacitive Touch
Power
Input Voltage 6.2V to 16.8V
Compatible Batteries 1 x NP-F / L-Series
Built-in battery No
Continuous power Via NPF battery or USB-C PD
DC-In Connector Via Battery Eliminator (separate purchase)
D-Tap Via optionally available Battery Eliminator or D-Tap to DC-Barrel Cable (separate purchases)
Display
Display Panel SuperAtom IPS Panel (Capacitive Touch)
Size 5.2-inch
Resolution 1920 x 1080
Viewing Angle 178 + H & V
PPI 427
Bit Depth 10-bit (8+2 FRC)
Backlight Type Edge-lit
Brightness (cd/m² / nits) 1500
Aspect Ratio 16:9
Color Gamut Rec.709
Calibration Support No
Color Pipeline
Gamma Sony S-Log / S-Log2 / S-Log3, Canon C-Log / C-Log 2 / C-Log3, Panasonic V-LOG, JVC J-Log1, Fujifilm F-Log / F-Log2, Nikon N-LOG / HLG, Olympus OM-LOG400 / FLAT, OM-System OM-LOG400 / FLAT, Leica L-LOG
Gamut BT2020, DCI P3, DCI P3 65, Sony SGamut / SGamut3 / SGamut3.cine, Canon Cinema / DCI P3 / DCI P3+ / BT.2020, Panasonic V Gamut, JVC LS300
3D LUT Display .Cube format (17 & 33 points supported)
3D LUT 50/50 Split Yes
Monitoring Modes SDR Native, HDR HLG, HDR PQ, 709 LUT, User LUT
Display Controls Backlight, Lift, Gamma, Gain
AtomHDR Built-in Technical Log to HDR EOTF
3D LUTs Load .Cube files from SD Card into 8 LUT Slots On-Device & use for Monitoring
Video Input
HDMI 1 x HDMI (1.4)
Bit Depth 8 / 10-Bit
Chroma Subsampling YCbCr 4:2:0 & 4:2:2
Audio In/Out
HDMI Embedded 2-channel, 24-bit, input dependent
Headphone Out 3.5mm headphone jack, 2-channel
Resolution and Frame Rates (Monitoring)
4K DCI No 4K DCI Resolution Support
4K UHD 23.98/24/25/29.97/30
FHD 1920 x 1080 Progressive 23.98/24/25/29.97/30/50/59.94/60
FHD 1920 x 1080 Interlaced 50i/60i
1280 x 720 Progressive 50/59.94/60p
Supported Media
SD Card Update firmware & upload LUTs
File System FAT32, NTFS
On-Screen Tools
MultiScope Analysis View Image, waveform, histogram, & vectorscope
Waveform 3 sizes – adjustable opacity & brightness
Histogram 3 sizes – adjustable opacity & brightness
RGB Parade 3 sizes – adjustable opacity & brightness
Vectorscope 1 size – adjustable opacity & brightness
1 x Zoom Tap to Zoom
2 x Zoom Tap to Zoom
4 x Zoom Tap to Zoom
Focus Peaking 4 modes (color, black & white, outline, edge sharpening) with adjustable outline color & peaking intensity
Colorized Exposure Atomos False Color
Zebra Adjustable threshold (50% to 105%)
Isolate Color Channel Blue only
Cine Frame Guides Presets for 2.41, 2.35, 1.91, 1.9, 1.85, 16:9
Social Frame Guides Presets for 9:16, 4:5, 2:3, 1:1, 5:4, 4:3, 3:2
Safe Areas SMPTE Safe Title Area – 93% & 90%
Grid Markers 9 grid
Display Flip Horizontal & Vertical
External Device Control
USB-C USB-C for device power
Serial 2.5mm Jack Use with Atomos calibration cables, and calibration software
What’s in the box
Included Shinobi GO, USB-C 2.0 cable, HDMI + USB-C locking cable adapter, Quick Start Guide
Optional Accessories Quick Release Monitor Mount, NP-F Battery Eliminator, DC to DTap Cable, Power Kit, HDMI cables, USB-C to serial cable
Warranty
Standard 1 year. Extended to 2 years on product registration

Additional information

Brand

Shinobi GO monitor, USB-C 2.0 cable, HDMI and USB-C locking cable adapter, Quick Start Guide
