Aida

UHD 4K/30 6G-SDI POV Camera

849,00 (ex. VAT)

SKU: UHD6G-200 Category:

The UHD6G-200 POV Professional EFP Camera from AIDA Imaging has a 1/2.5″ progressive-scan CMOS image sensor and supports a resolution of up to 4096 x 2160 at 20/24p fps. It features a preinstalled 3.2mm 12MP 4K lens and a 6G-SDI output and is designed for industrial and broadcast applications. This camera features a user-interchangeable C to CS mount lens as well as digital imaging processor that provides vivid and detailed images by utilizing dynamic range, white balance, and noise reduction. The on-screen display can be remotely controlled by a PTZ camera controller or by CCS-USB and software. A breakout cable with on-screen display control, audio input and RS-485 for remote communication as well as a 12 VDC power supply and socket adapter are included.

Video
Image Sensor
1/2.5″ progressive CMOS
Sensor Size
8.365 X 6.615 mm (16:9)
Effective Pixels
Horizontal: 3840
Vertical: 2160
Pixel Size
Horizontal: 1.62 μm
Vertical: 1.62 μm
Resolution
4096 X 2160, 3840 x 2160, 1920 x 1080, 1280 x 720
Resolution / Frame Rate
4K (4096 X 2160) at 20/24p
2160p at 30/29.97/25/24
1080p at 60/59.94/50/30/29.97/25/24
1080i at 60/59.94/50
720p at 60/59.94/50/30/25
Output
1 x HD/3G/6G-SDI BNC port
Color Space
4:2:2 (YCbCr) 10-bit
Function
White Balance
AWB / AE / AF
Exposure
Full auto, bright, shutter priority, iris priority, manual
Lens
Lens
C/CS mount
Audio
Input
3.5 mm analog audio jack over input/output cable
Sample Rate
16/24/32 bits
Standard
SMPTE
SMPTE 292M, SMPTE 424M, SMPTE 2081-10
Physical
Camera Control
RS-485
OSD Button
Power
12 VDC (9 to 15 VDC)
Operation Temperature
15 to 120°F / -9.4 to 48.9°C
Dimensions
2.20 x 2.20 x 2.83″ / 56 x 56 x 72 mm
Weight
0.37 lb / 170 g
Packaging Info
Package Weight
1.55 lb
Box Dimensions (LxWxH)
11.1 x 6.9 x 2.7″

Additional information

Brand

Reviews

There are no reviews yet.

Be the first to review “UHD 4K/30 6G-SDI POV Camera”

Your email address will not be published. Required fields are marked *

  • AIDA Imaging UHD6G-200 4K POV Professional EFP Camera
  • Input/Output Breakout Cable
  • 12 VDC Power Supply & Socket Adapter
  • Sensor Cap
  • C-Mount Lens Adapter
  • Hex Wrench
  • Terminal Power Connector
  • Limited 1-Year Manufacturer Warranty
