AJA

Open Gear DVI to 3G-SDI with Region of Interest Scaling

The AJA OG-ROI-DVI is the openGear card edition of the AJA ROI-DVI. It provides the same signal processing and conversion in a single-slot openGear card that installs in openGear and DashBoard-enabled frames for centralized, rack-based operation.

1.308,00€ (ex. VAT)

SKU: OG-ROI-DVI Categories: , , Brand:

The AJA OG-ROI-DVI brings the proven performance of the ROI-DVI to the openGear platform, delivering identical conversion and I/O capabilities (detailed in the technical specifications below) in a compact single-slot card. It is powered by the openGear frame and remotely configured and monitored through DashBoard.

The card is backed by a five year warranty.

Video Input

  • 1 x DVI input
  • Computer signals: up to WUXGA (1920 x 1200) 60 Hz; video signals: up to 1080p

Video Output Digital

  • SDI output up to 1080p (SMPTE 425, 4:2:2 10-bit YCbCr); ROI scaling, aspect-ratio and frame-rate conversion

openGear

  • Single-slot openGear card; compatible with openGear and DashBoard-enabled frames
  • Powered by the openGear frame (no external power supply required)
  • Remote configuration and monitoring via DashBoard

Environmental Specifications

  • Safe Operating Temperature: 0 to 40°C (32 to 104°F)
  • Safe Storage Temperature (Power OFF): -40 to 60°C (-40 to 140°F)
  • Operating Relative Humidity: 10-90% noncondensing
  • Operating Altitude: <3,000 meters (<10,000 feet)

Warranty

  • Five year warranty

Additional information

Brand

  • AJA OG-ROI-DVI openGear card

Requires an openGear frame (sold separately).
