The AJA FS-Mini synchronizes untimed 3G/HD/SD-SDI video to a house reference, with a single 3G-SDI input and output. It packs AJA’s production-proven frame-sync reliability into a compact Mini-Converter form factor.
AJA
3G-SDI Utility Frame Sync, SDI and HDMI simultaneous output
The AJA FS-Mini is a broadcast-quality utility frame synchronizer that brings AJA’s proven FS frame-sync technology to a portable, affordable Mini-Converter for 3G-SDI, HD and SD signals.
927,00€ (ex. VAT)
Video Formats
- 3G, HD and SD-SDI (Single Link 3G-SDI Level A)
Video Input Digital
- 1 x 3G-SDI BNC, SMPTE-259/292/424
Video Output Digital
- 1 x 3G-SDI BNC, SMPTE-259/292/424
Function
- Frame synchronization of untimed 3G/HD/SD-SDI sources to a reference
Physical
- Size (w x d x h): 5.8″ x 3.1″ x 1.0″ (147.32 x 78.74 x 25.4 mm)
- Weight: 0.7 lb (0.3 kg)
Power
- +5VDC regulated, 7.0 watts, power supply required (included with purchase)
Environmental Specifications
- Safe Operating Temperature: 0 to 40°C (32 to 104°F)
- Safe Storage Temperature (Power OFF): -40 to 60°C (-40 to 140°F)
- Operating Relative Humidity: 10-90% noncondensing
- Operating Altitude: <3,000 meters (<10,000 feet)
Warranty
- Five year warranty
Additional information
| Brand |
|---|
- AJA FS-Mini
- Universal power supply
