The AJA HA5-Plus is an HDMI to 3G-SDI Mini-Converter that integrates HDMI sources into SDI workflows for monitoring and recording in the edit suite, on set or at live events.
The AJA HA5-Plus converts an HDMI 1.4 input to 3G-SDI up to 1080p 60, embedding up to 8 channels of HDMI audio or a 2-channel analog (RCA) input into the SDI output. Convenient USB setup makes remote configuration easy.
A universal power supply is included and the unit is backed by a five year warranty.
Video Formats
SD and HD, up to 1080p 60
Video Input Digital (HDMI)
1 x HDMI Type A, HDMI v1.4
YCbCr 4:2:2/4:4:4/4:2:0, 8 or 10-bit (HFR 4:2:2 limited to 10-bit)
Video Output Digital
1 x 3G-SDI (Level A or B Dual Link); also 1.5G-SDI
Audio
HDMI embedded audio input, 24-bit, 8-channel
2-channel RCA analog audio input (-10 dBu nominal)
SDI embedded audio output, 24-bit, 8-channel
Physical
Size (w x d x h): 4.6″ x 2.4″ x 1.0″ (117 x 61 x 25 mm)
Weight: 0.3 lb (0.2 kg)
Power
Universal power supply included; 100-240VAC, 50/60 Hz universal input
Environmental Specifications
Safe Operating Temperature: 0 to 40°C (32 to 104°F)
Safe Storage Temperature (Power OFF): -40 to 60°C (-40 to 140°F)
